Cat gas gensets for reliable power supply

Cat power generators with gas or hydrogen drive

Our gas-powered power generators (400 to 4,500 kW) provide electricity and heat worldwide for various industries. The Cat generators come with standard equipment and numerous special options to meet specific requirements, and can operate flexibly with different types of gas, including up to 100% hydrogen. They guarantee durable, resilient power supply even under demanding conditions and ensure high plant availability.

Series CG132 B

The CG132 B series gas gensets offer power outputs between 400 kW and 1,000 kW and are ideal for power plants. They stand out for their fuel flexibility and can operate with various types of gas such as natural gas, biogas, landfill gas, sewage gas, coal mine gas, and up to 25% hydrogen. The new generation of CG132 B units excels with low gas consumption, reduced operating costs, optimized oil consumption, and an extended lifespan – an efficient and sustainable solution for modern energy needs.

Configuration	Frequency (Hz)	Electrical power (kW)	Useful heat output (kW)	Electrical efficiency (%)	Thermal efficiency (%)	Overall efficiency (%)
CG132B-08- P	50	400	419	43,4	45,5	88,9
CG132B-12-PH	50	495	567	42,7	48,9	91,6
CG132B-12-P	50	600	644	43,5	46,7	90,2
CG132B-16	50	800	817	43,9	44,9	88,8
CG132B-16-S	50	1,000	1,157	41,4	47,9	89,3

Do you have any questions about the CG132 B series? We would be happy to assist you.

CG132 B Series – Your solution for reliable power supply

The gas gensets of the CG132 B series offer outstanding benefits for efficient and cost-effective power supply. With an optimized oil consumption of only 0.1 g/kWhel, this series sets new standards in its class. The units enable longer oil change intervals, further facilitated by the integrated oil tank and day tank.

Thanks to low installation and operating costs, the CG132 B series proves to be highly economical. It offers an impressively long operating life before major overhauls, which can reach up to 80,000 operating hours with natural gas operation. The vibration-isolated base frame ensures easy installation and supports reliable operation throughout its service life.

The high availability and service life of the CG132 B units are further supported by optimized combustion technologies that ensure even cylinder charging and reduce peak pressures. This makes the units particularly smooth-running and minimizes vibrations during operation.

Another advantage is the improved turbocharger, which allows for longer maintenance intervals and provides a wider temperature window for intake air. With these technical benefits, the CG132 B series units offer a reliable and powerful solution for a wide range of applications.

Series CG170

The CG170 series offers powerful units ranging from 1,000 to 2,300 kW with low operating costs. They are flexible in fuel usage and can operate with natural gas, biogas, propane, and up to 25% hydrogen. With an electrical efficiency of up to 45.3%, the units provide high recoverable heat and reduce carbon emissions. Under various environmental conditions, performance remains optimal. Additionally, they can be equipped with retrofit kits for operation with hydrogen blends, making them a sustainable and future-proof solution.

Configuration	Frequency (Hz)	Electrical power (kW)	Useful heat output (kW)	Electrical efficiency (%)	Thermal efficiency (%)	Overall efficiency (%)
CG170-12-RW	50	1,000	1,080	43,4	46,9	90,3
CG170-12	50	1,200	1,189	44,1	43,7	87,8
CG170B-12-P	50	1,380	1,359	45,1	43,5	88,6
CG170-16	50	1,560	1,618	43,7	45,3	89
CG170B-16-P	50	1,840	1,802	44,8	43,8	88,6
CG170-20	50	2,000	1,937	44,6	43,2	87,8
CG170B-20-P	50	2,300	2,214	45,3	43,6	88,9

Do you have any questions about the CG170 series? We would be happy to assist you.

Low operating costs with CG170 gas gensets

The gas gensets of the CG170 series offer an efficient and cost-effective solution for power generation, with a particularly high output range of 1,000 to 2,300 kW. They are flexible in fuel usage and can operate with various types of gas, including natural gas, biogas, and propane. These units achieve electrical efficiencies of up to 45.3%, ensuring high energy yield and optimizing heat recovery.

The CG170 series is particularly robust and designed for a wide range of environmental conditions. Whether faced with fluctuating temperatures, high humidity, or varying air pressure conditions, the units provide reliable performance and low carbon emissions. With this efficiency and environmental friendliness, the CG170 gensets are ideal for applications where reliability and sustainability are key, such as in industrial plants and decentralized power generation.

Another feature of the CG170 series is its compatibility with hydrogen: the units can operate with up to 25% hydrogen. Zeppelin Power Systems also offers retrofit kits that enable existing units to be equipped for use with hydrogen blends, thereby enhancing the flexibility and future-proofing of the systems.

With optimized combustion technology, reduced maintenance requirements, and adaptable control systems, the CG170 gas gensets provide a durable and powerful solution for various applications. This combination of efficiency, robustness, and future readiness makes the CG170 series an ideal choice for sustainable and economical power supply.

Series 3500 H

The units of the 3500 H series, with a power output ranging from 1,516 to 2,526 kW, are versatile and robust power sources. They stand out for their easy installation and commissioning. With a wide selection of generators, auxiliary equipment, controls, exhaust options, communication modules, and battery chargers, they can be easily customized to meet specific requirements.

Configuration	Frequency (Hz)	Electrical power (kW)	Useful heat output (kW)	Electrical efficiency (%)	Thermal efficiency (%)	Overall efficiency (%)
G3512HR	50	1,516	1,512	44,8	44,6	89,4
G3516HR	50	2,019	1,918	45,1	42,8	87,9
G3520HR	50	2,526	2,428	45,2	43,4	88,6

Do you have any questions about the G3500 H series? We would be happy to assist you.

Sustainable power generation with hydrogen blending

The Cat gas gensets of the 3500 H series provide reliable and flexible power supply solutions in the range of 1,500 kW to 2,500 kW for demanding applications. These units are designed for maximum efficiency and durability, with a robust construction that ensures consistent operation even under challenging conditions. With a wide range of customization options—including various generators, controls, exhaust options, as well as communication modules and battery chargers—the 3500 H series models can be easily tailored to meet specific customer requirements.

A standout feature of the 3500 H series is its ability to operate both environmentally friendly and cost-effectively. In addition to natural gas as the primary fuel, these units can utilize hydrogen blends of up to 25% by volume, further reducing operating costs and emissions. The G3516 H model can even operate with 100% hydrogen, offering a particularly sustainable solution. This flexibility makes the 3500 H series not only a reliable choice for power generation but also a future-proof investment for companies looking to improve their carbon footprint.

The 3500 H units offer an economically and environmentally conscious option for industries and other energy-intensive applications with their optimized design and low maintenance requirements.

Series CG 260

The CG260 series offers high power outputs of up to 4,500 kW. The gas gensets consistently operate reliably, flexibly, efficiently, and environmentally friendly. They cover a wide range of applications and ensure high cost-effectiveness.

Configuration	Frequency (Hz)	Electrical power (kW)	Useful heat output (kW)	Electrical efficiency (%)	Thermal efficiency (%)	Overall efficiency (%)
CG260-12	50	3,333	3,270	44,5	43,7	88,2
CG260-16	50	4,300	4,269	44,3	43,9	88,2
CG260B-16	50	4,500	4,461	44,8	44,4	89,2

Do you have any questions about the CG260 series? We would be happy to assist you.

CG260 Gas Generator: Maximum Efficiency and Performance

The CG260 gas generator offers outstanding efficiency and performance. With improvements in turbocharging, system control, and optimized pre-chamber spark plugs, it achieves an electrical efficiency of up to 44.8%. This ensures exceptionally high energy yield and low operating costs.

Thanks to optimized engine components, the CG260 consumes up to 30% less lubricating oil than comparable gas generators, leading to reduced service costs. The particulate-free combustion and chamber spark plugs enable longer maintenance intervals and improved heat utilization, extending the operating time by an average of 200 hours per year compared to other systems.

The CG260 is also reliable in demanding environments. Thanks to the new high-performance wastegate turbocharger A140, the unit can operate at full capacity even with intake air temperatures of up to 45°C (113°F), ensuring stable load behavior even at higher altitudes.

Key benefits for your Organization

High energy efficiency

Our Cat gas gensets are known for their high fuel efficiency, leading to a significant reduction in operating costs. Especially in the power and heat sectors, where energy savings are crucial, these units provide an economical solution.

Reliable power and heat generation

The Cat gas gensets provide stable and reliable energy, both for base load supply and peak load demands. This makes them ideal for continuous operation in the power and heat sectors, where uninterrupted supply is crucial.

Low emissions and environmental friendliness

Caterpillar gas gensets are equipped with low-emission technologies that minimize CO₂ emissions and ensure compliance with stringent environmental regulations.

Flexibility through the use of different fuels

Many of our gas gensets can operate with a variety of fuels, including natural gas, biogas, and hydrogen. This flexibility allows for adaptation to different fuel sources, providing businesses with greater independence in power generation.

Maximized uptime through reduced maintenance costs

Thanks to their robust construction and advanced technologies, our gas gensets are designed for continuous operation and require minimal maintenance. This results in higher availability and less downtime, which is crucial for the power and heat sectors.

Comprehensive service from Zeppelin Power Systems

Zeppelin Power Systems offers not only powerful Cat gas gensets but also comprehensive solution concepts and service packages, ranging from planning and installation to maintenance and servicing. This holistic support ensures safe and efficient operation throughout the entire lifecycle of the system.
