C175-16 Tier 4 Final
CAT
C175-16 Tier 4 Final
Direct Inquiry

CAT C175-16 Tier 4 Final

Minimum Rating

2500.0 kVA

Maximum Rating

3100.0 kVA

Rated Speed

1800 rpm

Exposé
Electric Power Rating Guide C175-16 2500 - 3000 ekW 60 Hz Diesel Generator Set, US EPA Tier 4 Final C175-16 2600 - 3100 ekW 60 Hz Diesel Generator Set, US EPA tier 4 Final
Direct Inquiry

Salutation *

Surname
First name
Company
Customer number
Position

Address

Street & Streetnumber
Zip
City
Country

Contact information

E-Mail
Country code
Area code
Phone number

For which industry do you request?

* Required field

You will find information on the handling of your personal data in our data protection statement.

Any questions? Get in touch.
Phone: +49 4202 91460
Service Hotline: 0800- 589 27 87
(outside of Germany: +49 40 853 151-222)

Description

Caterpillar is leading the power generation marketplace with Power Solutions engineered to deliver unmatched flexibility, expandability, reliability, and cost-effectiveness.

Product Specifications

Engine Specifications
Engine Model

C175-16 SCAC, V-16, 4-Stroke Water-Cooled Diesel

Bore

175.0 mm

Stroke

220.0 mm

Displacement

84.67 l

Compression Ratio

16:07:01

Aspiration

Turbo Aftercooled

Fuel System

EUI

Governor Type

ADEM™ A4

Generator Set Dimensions
Length - Minimum

6166.3 mm

Length - Maximum

7928.7 mm

Width - Minimum

2110.1 mm

Width - Maximum

3123.3 mm

Height - Minimum

2211.3 mm

Height - Maximum

3613.3 mm

Dry Weight - Genset (minimum)

19391.0 kg

Dry Weight - Genset (maximum)

20463.0 kg

Generator Set Specifications
Minimum Rating

2500 ekW

Maximum Rating

3100 ekW

Emissions/Fuel Strategy

U.S. EPA Certified

Voltage

480 to 13800 Volts

Frequency

60 Hz

Speed

1800 rpm

Duty Cycle

Standby, Mission Critical, Prime, Continuous

Power Rating
Maximum Rating

3100.0 kVA

Minimum Rating

2500.0 kVA

Rated Speed

1800 rpm
